Technical Specifications
| D C | NPN |
| PNP | C3Z-TOF1P |
| Response time | 10ms |
| Specification | Diffuse reflective TOF |
| Humidity range | Operation, storage: 35～85% (no condensation) |
| Supply Voltage | DC12～24V |
| Indicator light | Green power indicator, red action indicator |
| Residual voltage | ≤2.5V |
| Operating current | Load current≤100mA；Static current：≤20mA |
| Temperature range | Operating: -25～+55℃ (no icing, condensation); Storage: -30～+70℃ (no icing, condensation) |
| Detectable objects | Reflecting object |
| Protection circuit | Polarity, overcurrent and overload protection |
| Detection distance※1 | 50 ～ 1000mm(Adjustable) |
| Sensitivity adjustment | One-touch button setting |
| Sensing surface material | PC |
| Ambient illuminance range | Incandescent: Spot intensity under 10,000Lx |
| Standard detection object | 10×10cmWhite non-glossy paper |
