Technical Specifications
| Specification | CHJY Series |
| Humidity range | Operation, storage: 35～95% (no condensation) |
| Supply Voltage | DC10~30V |
| Indicator light | 360° (yellow) |
| Leakage current | When 24VDC ，max 0. 1mA |
| Housing Material | Chrome Plated Brass |
| Residual voltage | NPN ：≤ 2.5V;PNP ：≤ 2.5V |
| Operating current | DC(NPN,PNP) ：≤ 180mA |
| Return Difference | Less than 15 % of detection distance |
| Temperature range | Operating: -25～+70℃ (no icing, condensation); Storage: -40～+85℃ (no icing, condensation) |
| Detectable objects | Magnetic metals (shorter detection distances for non-magnetic metals) |
| Protection circuit | Polarity, Overcurrent protection |
| Sensing surface material | ABS |
| Temperature effect (drift) | -25～+70℃ temperature range, the detection distance is within ±15% of the detection distance at +23℃ |
