Technical Specifications
| Ui | 400V |
| Ith | 5A |
| Uimp | 2.5KV |
| Ue/Ui | Rated working voltage Ue/rated working current Ie:AC-15 Ue:AC250V,Ie:3A for each category of use. |
| Remarks | Only contact signal counting is possible. If photoelectric switch/proximity switch counting is required, please choose HHJ1 model |
| Dimensions | 48×48×105mm |
| Output mode | N, C, F, R, X format |
| Input signal | Contact signal counting |
| Opening size | 45×45mm |
| Working mode | Positive counting, 4-digit LED display |
| Specification | DH48S |
| Counting range | 0.01s~99.99s;1s~99m99s;1m~99h99m |
| Counting speed | High frequency 100 times/second; low frequency 30 times/second |
| Operating Mode | Power-on delay |
| Operating power | AC380V, 220V, 110V,36V,24V,50Hz, permissible voltage fluctuation range is (85%~110%) Ue |
| Contact capacity | 3A AC250V (resistive) |
| Repetition error | Er<1% when the delay range is greater than 1s; Dr<50ms when the delay range is less than 1s. |
| Temperature range | -5°-40°C |
| Number of contacts | 1 set of delayed transitions |
| Installation method | Panel type |
| Power failure memory | Memory can be set |
| Working power supply | AC/DC24V; AC/DC100~240V; AC380V |
