Solid-State Relay HHG41 Series

Name: Solid-State Relay HHG41 Series
Brand: C-Lin
SKU: HHG41-0/032F-06-D

Model Number: HHG41-0/032F-06-D

Control voltage: 3-32VDC Control current: 5-20mA Load voltage: 06: 5-60VDC Load current: 1A, 2A On-state voltage drop: DC≤1.2VAC Control protection: DC≤5ms Off-state leakage current: DC≤5ms Dielectric withstand voltage: ≥ 1500VAC Ambient temperature: -30~80℃ Dimensions: 28×18.5×5mm Installation form: single in-line plug-in Description: Install next to a heat dissipation window with good ventilation Note: Adapter socket 41F-1Z-C2N 5V

Request Quote

Technical Specifications

Model	HHG41-0/032F-06-D
Dimension	28×18.5×5mm
Instruction	Installed next to well ventilated heat dissipation window
On-off time	AC≤ 5ms
Load current	1A, 2A
Load voltage	06: 5-60VDC
Ambient temp.	-30~80°C
Control current	5-20mA
Control voltage	3-32VDC
Installation form	Single line direct plug-in
Dielectric strength	≥ 1500VAC
On-state voltage drop	AC ≤ 1.2VAC
Off-state leakage current	AC ≤ 5mA
